Compression and Torsion Spring Machine SH-8II
SH-8II 1 Point Coiling machine
  • Item number: SH-8II
Price on application
Available now!
question
Description
Short Information
Description

Coiling machine with coiling point


1-point coiling machine with a wire diameter of 0.1 to 0.8 mm

  • Maximum outer coil diameter of 20 mm
  • Equipped with 7 standard axes: feed, cut, pitch, point, torsion, initial tension, and MSD-1.
  • Optional core forward/reverse servo unit provided.
  • Easier setup and greater speed than previous models, as the cut axis and torsion axis are separated.
  • Suitable for high-speed production of torsion springs and elliptical springs in addition to standard cylindrical springs.

    • Taper synchronization constant

  • Enables the taper tilt to be managed with a value from 0 to 100.
  • uitable for load adjustment in addition to shape adjustment, as fine adjustment can be performed in 100 levels.

    • Dedicated MNO Program for Spring Production

  • Easy operations for quicker preparation.
  • High resolution for controlling the latest servo motors.
  • Compatible with compression spring creation programs based on line graphs.
  • Allows varied control based on measurement results, such as the pitch and diameter.
  • Common program for both torsion machines and coiling machines.
  • Includes a motor sensor system.
  • Versatile production management screen and production data collection function.

    • Optional Equipment

  • Core forward/reverse servo unit
  • Slip sensor to detect slips in wire feeding
  • Capacitance level sensor
  • IS-1 shape detection unit with camera
